| Model |
GWN7615 |
| Wi-Fi Standards |
IEEE 802.11 a/b/g/n/ac (Wave-2) |
| Antennas |
3 dual band internal antennas
2.4GHz, gain 3dBi
5 GHz, gain 3dBi |
| Wi-Fi Data Rates |
IEEE 802.11ac: 6.5 Mbps to 1300Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 450 Mbps
IEEE 802.11b: 1, 2, 5.5, 11Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Frequency Bands |
2.4 GHz Radio: 2412-2484 MHz
5 GHz Radio: 5180-5825 MHz |
| Channel Bandwidth |
2.4G: 20 and 40MHz
5G: 20, 40, and 80MHz |
| Wi-Fi and System Security |
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
| MIMO |
3×3:3 2.4G(MIMO)
3×3:3 5G(MU-MIMO) |
| Coverage Range |
Up to 175 meters |
| Maximum TX Power |
2.4G: 26 dBm
5G: 24 dBm |
| Receiver Sensitivity |
- 2.4G: 802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
- 5G: 802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:-
63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9 |
| SSIDs |
16 SSIDs per access point |
| Concurrent Clients |
200+ |
| Network Interfaces |
2x autosensing 10/100/1000 Base-T Ethernet Ports |
| Auxiliary Ports |
1x Reset Pinhole, 1x Kensington lock |
| Mounting |
Indoor wall mount or ceiling mount, kits included |
| LEDs |
3 x tri-color LEDs for device tracking and status indication |
| Network Protocols |
IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
| QoS |
802.11e/WMM, VLAN, TOS |
| Network Management |
Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN APs
GWN Manager offers premise-based software controller for up to 3,000 GWN APs |
| Power and Green Energy Efficiency |
PoE 802.3af/ 802.3at;
Max Consumption: 12.5W |
| Environmental |
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing |
| Physical |
Unit Dimension: 205.4 x 205.4 x 45.9mm; Unit Weight: 500g
Entire Package Dimension: 258 x 247 x 86mm; Entire Package Weight: 867.3g |
| Package Content |
GWN7615 802.11ac Wireless AP, Mounting Kits, Quick Start Guide |
| Compliance |
FCC, CE, RCM, IC |
